Features:

  • PIN diode T/R switching for full QSK
  • Built-in temperature sensing with automatic over-temperature shut-down
  • Separate BNC antenna connector on K3 rear panel
  • Field upgradeable with built-in diagnostic and troubleshooting commands

General

  • Frequency Range: 144-148 MHz
  • I.F. Range: 28-30 MHz
  • Dimensions (HWD): 1x3.2x5 inches (2.5x8.1x12.7 cm)
  • Supply Voltage: 13.8 VDC
  • Typical Current Consumption:  Transmit: 2A, Receive: 0.25A, Off: 0.01A

Transmit

  • Power Output: 8 to10W Typical (13.8 V at the K3 in Transmit. Lower voltages will reduce the maximum power out)
  • Spurious Output: < -60 dBc

Receive

  • Noise Figure: 1 dB typical
  • Gain: 20 dB typical

Q: How difficult is it to install the K144XV?

A: Only a few basic hand tools are needed to perform the installation. A minimal amount of soldering is required to install a power connector on the K3 RF board on some older K3 transceivers.

Q: When would I need to consider the RefLock option?

A: If you are planning on operating FM only, then you will not need to install the RefLock option.  If, however, you plan to operate CW, Sideband or AM modes, install the RefLock option to maximize stability.




K144XV Internal Module Quantity Price
K144XV K144XV 144-148 MHz 10 W Internal Module, Kit $589.95
